Product: 06.BJ.423

HomeCatalog06.BJ.423
product
Technical Drawing

06.BJ.423 - Ball Joint

ETS No:

06.BJ.42306.BJ.430

OEM No:

1 417 3521451914176371318177524 173 7614 381 9274 616 978404145441207344630551KT6C11 3K209 BAKTBK213K209ABKTYC153468AFYC1A3395BAYC1A3395CA

Product Group:

Ball Joint

Product Position:

Lower

Product Status:

Active Product

Brand:

FORD

Model:

TRANSIT CONNECT (P65_, P70_, P80_) 1.8 TDCi

Year:

08.2006 - 12.2013

Body Type:

MPV Van

Product Features

Weight:

0.64 kg

Gear Dimension:

M16x1,5 RHT

Material:

Forged Steel

Barcode:

8681335125747

Compatible Vehicles

BrandModelYearBody Type
FORDTOURNEO CONNECT 1.8 16V06.2002 - 12.2013MPV
FORDTOURNEO CONNECT 1.8 TDCi06.2002 - 12.2013MPV
FORDTOURNEO CONNECT 1.8 TDCi08.2006 - 12.2013MPV
FORDTOURNEO CONNECT 1.8 TDCi /TDDi /DI06.2002 - 12.2013MPV
FORDTOURNEO CUSTOM V362 Bus (F3) 2.0 EcoBlue12.2015 - 12.2023Bus
FORDTOURNEO CUSTOM V362 Bus (F3) 2.2 TDCi09.2012 - 12.2015Bus
FORDTRANSIT Bus (E_ _) 2.5 DI08.1997 - 03.2000Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.0 DI08.2000 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.0 TDCi08.2002 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi10.2011 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi04.2006 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi10.2007 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi10.2008 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi RWD10.2011 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi RWD09.2011 - 12.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi RWD09.2011 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.3 16V RWD08.2000 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 DI01.2000 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 DI RWD01.2000 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 DI RWD01.2000 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi03.2004 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi04.2006 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi 4x411.2006 - 08.2014Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDE07.2001 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDE03.2004 - 05.2006Bus
FORDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 3.2 TDCi02.2008 - 08.2014Bus
FORDTRANSIT CONNECT (P65_, P70_, P80_) 1.8 16V06.2002 - 12.2013MPV Van
FORDTRANSIT CONNECT (P65_, P70_, P80_) 1.8 16V LPG06.2002 - 12.2013MPV Van
FORDTRANSIT CONNECT (P65_, P70_, P80_) 1.8 Di06.2002 - 12.2013MPV Van
FORDTRANSIT CONNECT (P65_, P70_, P80_) 1.8 TDCi06.2002 - 12.2013MPV Van
FORDTRANSIT CONNECT (P65_, P70_, P80_) 1.8 TDCi08.2006 - 12.2013MPV Van
FORDTRANSIT CUSTOM V362 Bus (F3) 2.0 EcoBlue12.2015 - 12.2023Bus
FORDTRANSIT CUSTOM V362 Bus (F3) 2.2 TDCi09.2012 - 12.2015Bus
FORDTRANSIT CUSTOM V362 Van (FY, FZ) 2.0 EcoBlue12.2015 - 12.2023Van
FORDTRANSIT CUSTOM V362 Van (FY, FZ) 2.2 TDCi09.2012 - 12.2015Van
FORDTRANSIT CUSTOM V362 Van (FY, FZ) 2.2 TDCi09.2012 - 12.2023Van
FORDTRANSIT Platform/Chassis (E_ _) 2.5 DI05.1999 - 03.2000Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.0 DI08.2000 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.0 TDCi08.2002 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V04.2001 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 BiFuel03.2001 - 03.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 DI01.2000 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi03.2004 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDE07.2001 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDE03.2004 - 05.2006Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi10.2011 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi04.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi10.2007 - 09.2011Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi10.2008 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi 4x410.2011 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi RWD10.2011 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.3 16V CNG RWD04.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.3 16V LPG RWD04.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.3 16V RWD04.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.4 TDCi 4x411.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.4 TDCi RWD04.2006 - 08.2014Platform/Chassis
FORDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 3.2 TDCi RWD09.2007 - 08.2014Platform/Chassis
FORDTRANSIT TOURNEO Bus 2.2 TDCi07.2006 - 08.2014Bus
FORDTRANSIT TOURNEO Bus 2.2 TDCi10.2007 - 08.2014Bus
FORDTRANSIT TOURNEO Bus 2.2 TDCi10.2008 - 08.2014Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.0 EcoBlue03.2016 -Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.0 EcoBlue03.2016 - 06.2024Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.2 TDCi08.2013 - 12.2018Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.2 TDCi12.2014 - 12.2018Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.2 TDCi 4x408.2013 - 12.2018Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.2 TDCi All-wheel Drive08.2015 - 12.2018Bus
FORDTRANSIT V363 Bus (FAD, FBD) 2.2 TDCi RWD08.2013 - 12.2018Bus
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue03.2016 -Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue03.2016 - 06.2024Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue 4x401.2017 -Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue 4x401.2017 - 06.2024Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue RWD03.2016 -Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.0 EcoBlue RWD03.2016 - 06.2024Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.2 TDCi08.2013 - 12.2018Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.2 TDCi 4x408.2013 - 12.2018Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.2 TDCi RWD08.2013 -Platform/Chassis
FORDTRANSIT V363 Platform/Chassis (FED, FFD) 2.2 TDCi RWD08.2013 - 12.2018Platform/Chassis
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue03.2016 -Van
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue03.2016 - 06.2024Van
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue 4x401.2017 -Van
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue 4x401.2017 - 06.2024Van
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue RWD03.2016 -Van
FORDTRANSIT V363 Van (FCD, FDD) 2.0 EcoBlue RWD03.2016 - 06.2024Van
FORDTRANSIT V363 Van (FCD, FDD) 2.2 TDCi08.2013 - 12.2018Van
FORDTRANSIT V363 Van (FCD, FDD) 2.2 TDCi 4x408.2015 - 12.2018Van
FORDTRANSIT V363 Van (FCD, FDD) 2.2 TDCi 4x408.2013 - 12.2018Van
FORDTRANSIT V363 Van (FCD, FDD) 2.2 TDCi RWD08.2013 - 12.2018Van
FORDTRANSIT Van (E_ _) 2.5 DI05.1999 - 03.2000Van
FORDTRANSIT Van (FA_ _) 2.0 DI08.2000 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.0 TDCi08.2002 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi10.2011 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi04.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi10.2007 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi10.2008 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi 4x410.2011 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi RWD10.2011 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.2 TDCi RWD09.2011 - 12.2014Van
FORDTRANSIT Van (FA_ _) 2.303.2001 - 03.2006Van
FORDTRANSIT Van (FA_ _) 2.3 16V CNG RWD04.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.3 16V LPG RWD04.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.3 16V RWD04.2001 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.3 16V RWD04.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.4 DI01.2000 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.4 DI RWD01.2000 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.4 TD08.2000 - 08.2003Van
FORDTRANSIT Van (FA_ _) 2.4 TDCi03.2004 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.4 TDCi 4x411.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.4 TDCi RWD04.2006 - 08.2014Van
FORDTRANSIT Van (FA_ _) 2.4 TDE07.2001 - 05.2006Van
FORDTRANSIT Van (FA_ _) 2.4 TDE03.2004 - 05.2006Van
FORDTRANSIT Van (FA_ _) 3.2 TDCi RWD09.2007 - 08.2014Van
